Source
Light source: 12x 15W RGBW multichips

LED Life Expectancy: minimum 60.000 hours

Typical Lumen Maintenance: 70% @ 60.000 hours

Optical system
Robe’s proprietary optical design

Beam angle: 7°

Fixture total lumen output: 3.220 lm

Light output: 5.960 lm @ 5 m

Dynamic Effects and Features
Colour mixing mode RGBW or CMY

3 individually controllable LED zones

Virtual Colour Wheel: 237 colours including whites (2.700K, 3.200K, 4.200K, 5.600K and 8.000K)

Tungsten lamp effect at whites: 2.700K and 3.200K (red shift and thermal delay)

Colour rainbow effect with variable speed

Pre-programmed random strobe & pulse effects

Electronic strobe effect with variable speed up to 20 Hz

High resolution electronic dimming: 0 - 100%

Control and programming
Setting & Addressing: two-row LCD display & 4 control buttons, stand-alone operation with 6 editable programs (each up to 25 steps)

Protocols: USITT DMX-512, RDM

Wireless CRMX™ technology from Lumen Radio: On request

DMX Protocol modes: 6

Control channels: 35, 19, 14, 9, 35, 37

Pan/Tilt resolution: 8 or 16 bit

RGBW or CMY: 8 or 16 bit

Dimmer: 8 or 16 bit

Movement
Pan movement: 450°

Tilt movement: 300°

Automatic Pan/Tilt position correction

Thermal specification
Maximum ambient temperature: 45°C (113°F)

Maximum surface temperature: 80°C (176°F)

Minimum operating temperature: -5°C (23°F)

Electrical specification and connections
Power supply: Electronic auto-ranging

Input voltage range: 100-240 V, 50/60 Hz

Power consumption: Max. 200 W at 230 V / 50 Hz

Power in/out connector: Neutrik powerCON in/out

DMX and RDM data in/out: Locking 5-pin XLR

Ethernet port in: RJ45

Mechanical specification
Height: 314 mm (12.4")

Width: 233 mm (9.2")

Depth: 149 mm (5.9")

Weight: 4.5 kg (9.9 lbs)
